2D and 3D file downloads now available

Published by Michael Johnston on 23rd Jan 2023

We have made 2D and 3D technical files available for 920+ Omega Products part numbers.

These are free to download in .PDF .DXF and .STEP file types. We will continue to add additional files to the website as they become available.

The files can be found displayed as a table at the bottom of product pages on the website e.g.  https://trucuttools.co.uk/dv50-er40-collet-chucks/


Part Number File Download
OM31238 OM31238.DXF
OM31238.PDF
OM31238.STEP
OM31878 OM31878.DXF
OM31878.PDF
OM31878.STEP
OM31475 OM31475.DXF
OM31475.PDF
OM31475.STEP
OM31879 OM31879.DXF
OM31879.PDF
OM31879.STEP
OM31880 OM31880.DXF
OM31880.PDF
OM31880.STEP
OM31881 No File Available
No File Available
No File Available

The following CAD Directory List UK Master.xlsx is available in Excel format to quickly view what files are currently available and recently added.
